Sanyo UR18650ZY 2500mAh

Reference: UR18650ZY

Condition: New product

SANYO UR18650ZY 2500 mAh Flat Top

Specifications:
Minimum Capacity: 2450 mAh (4.20V)
Typical Capacity: 2600mAh (4.20V)
Nominal Voltage: 3.7V
Standard Charging Current: 1.51A
Max Continuous Discharging Current: 5.0A
Date Code: 2022
Sorted and repacked

More details

Write a review

Send to a friend

Send to a friend

Sanyo UR18650ZY 2500mAh

SANYO UR18650ZY 2500 mAh Flat Top

Specifications:
Minimum Capacity: 2450 mAh (4.20V)
Typical Capacity: 2600mAh (4.20V)
Nominal Voltage: 3.7V
Standard Charging Current: 1.51A
Max Continuous Discharging Current: 5.0A
Date Code: 2022
Sorted and repacked

Recipient :

Name of your friend ^* :

E-mail address of your friend ^* :

^* Required fields

or Cancel
Print

More info

Specifications

Item	Specifications	Notes
5.1 Rated Capacity	2450mAh	4.20V
5.2 Capacity (Minimum)	2500 mAh	4.20V
5.3 Capacity (Typical)	2600 mAh	4.20V
5.4 Nominal Voltage	3.7V	0.81A discharge
5.5 Discharging End Voltage	3.0V	-
5.6 Charging Current (Std.)	1.75A	-
5.7 Charging Voltage	4.20 ± 0.03V	-
5.8 Charging Time (Std.)	3.0 hours	-
5.9 Cont' Current (Max.)	5.0A	0 ~ +40 ^oC
5.10 Internal Resistance	Less than 100 mOhm	AC impedance 1 kHz
5.11 Weight	Less than 48.0g	-
5.12 Operating Temperature	Charge: 0 ~ +45 ^oC Discharge: -20 ~ +60 ^oC	-
5.13 Storage Conditions	Less than 1 month: -20 ~ +50 ^oC Less than 3 months: -20 ~ +40 ^oC Less than 1 year: -20 ~ +20 ^oC	Recoverable Capacity: 80%
