LFP 1286 Lithium Battery 12V 86AH View larger

LFP 12100 Lithium Battery 12V 100AH

SLA replacement batteries

New product

Features:
Attractive cycle life

Extended safety performance
Wide operating temperature range
Unrivalled high temperature performance
Green energy without metal contaminant
High capacity
Steady output voltage
Little self-discharge
Double safety protection
  • Housing: IP56 ABS case
  • Size: 313*230*220mm
  • BMS: 100A BMS, 260A peak 5S
  • Weight: approx. 15kg
  • Terminal: M8
  • Cycle life: 5000+
  • Warranty: 5 years

More details

Warning: Last items in stock!

$389.00 tax excl.

The minimum purchase order quantity for the product is 20

Add to wishlist

More info

This 4S1P Lithium battery pack uses high quality prismatic cells (3.2V 100AH) and reliable protection circuit modules (PCM). The module type battery packs can be used to expand to 6 in series and 6 in parallels to reach up to 72V and high capacity. They are widely used in ESS (energy storage system), sold energy systems, fork lift, power wall, etc.
The cells are certified with UN38.3 and UL1642.
  • BMS temperature protection:
  • Charge Cut-off @ 0 ℃
  • Charge Cut-off @52℃
  • Discharge Cut-off @ 65℃
  • Balance
  • Max. 6 in series/parallel

Please feel free to contact us for purchasing and/or standard datasheet or OEM designs.

Battery type Lifepo4 battery
Rated Voltage 12.8v
Capacity 100Ah
Charge current 100A
Discharge current 100A  260A peak
Dimension 313*230*220mm
Case  abs
Life cycle >5000 times
Charge voltage 14.6v
Cut off voltage 10v
Weight 15kg

Reviews

Write a review

LFP 12100 Lithium Battery 12V 100AH

LFP 12100 Lithium Battery 12V 100AH

Features:
Attractive cycle life

Extended safety performance
Wide operating temperature range
Unrivalled high temperature performance
Green energy without metal contaminant
High capacity
Steady output voltage
Little self-discharge
Double safety protection
  • Housing: IP56 ABS case
  • Size: 313*230*220mm
  • BMS: 100A BMS, 260A peak 5S
  • Weight: approx. 15kg
  • Terminal: M8
  • Cycle life: 5000+
  • Warranty: 5 years
