SIB-O-32140-10Ah Sodium Ion Battery
New product
The SIB-O-32140-10Ah Sodium-Ion Battery offers 10Ah capacity, 30Wh energy, and 3.0V nominal voltage. It supports up to 0.5C charge, 10C continuous discharge, and 15C peak. Operating from -40°C to 60°C, it features ≤3mΩ impedance, 265g weight, and reliable performance with 50% SOC storage at -20~30°C.
Rating
More info
| Parameter | Specification | Remarks |
| Nominal Capacity | 10Ah | Fresh battery, 0.2C charge and discharge@25°C |
| Nominal Energy | 30Wh | |
| Nominal Voltage | 3.0V | |
| Charge Cut-off Voltage | 4.0V | Charge cut-off current is 0.02C |
| Discharge Cut-off Voltage | 1.5V | |
| Impedance (1KHz) | ≤3mΩ | AC Impedance 1kHz |
| Shipping Voltage | ≥3.0V | |
| Weight | 265±5g | |
| Storage Temperature | -20~30°C |
(About 50% SOC storage) Humidity < 60% |
| Charge Temperature |
-10°C~-5°C -5°C~0°C 0°C~45°C |
0.1C 0.2C 0.5C |
| Standard Charge Current | 0.2C | 2A |
| Maximum Charge Current | 0.5C | 5A |
| Discharge Temperature | -40°C~60°C | |
| Standard Discharge Current | 0.2C | 2A |
| Maximum Continuous Discharge Current | 10.0C | 0-45°C |
| Maximum Instantaneous Discharge Current | 15.0C | 0-45°C, 3S |
